digicon-200
Introduction:
Our digicon® series offers electric modulating actuators with torque range of 20Nm–6000Nm, available in both male (protruding drive shaft) and female (hollow socket) types for different connection interfaces.
Standard Specification
Model | digicon-200 |
Torque (Nm) | 2000 |
Power Supply | 24V AC/DC 220/110V AC |
Flange (ISO 5211) | F14 |
Stroke Time for 50Hz (sec) | 100 |
Motor Power (In/out) | 300/90 |
Input Signal | 4-20mA 0-10V |
Output Signal | 4-20mA 0-10V |
Weight (kg) | 12.8 |
Enclosure Rating | IP68 |
Ambient temperature | –40°C (space heater required) to 55°C –40°F (space heater required) to 131°F |
Duty Cycle (AC units) | 50% |
Duty Cycle (DC units) | 100% |
Installation Angle | 360° at any angle |
Insulation | F Class |
Certifcation | CE |
Dimensional Drawing
ulli-100/200 & digicon-100/200
unit: cm
Female Type:
Male Type:
Valve Compatibility
For reference only:
Compatible Ball Valves | DN150-DN200 |
Compatible Butterfly Valve | DN400-DN500 |
Options / Add-Ons
Option | Description | Free/Chargable |
Viewing window type | Flat viewing window or spherical viewing window | Free |
Drive connection | Female recessed connection or male protruding connection | Free |
Outer cover colour | Black, blue, or gray housing | Free |
Output shaft types | Four square, round hole, double D, or keyed output shaft | Free |
Voltage options | AC 220 V single phase, AC 380 V three phase, AC 110 V single phase, AC 24 V single phase, DC 24 V, DC 220 V | Free |
Handwheel | Manual handwheel with mechanical disengagement | Chargable |
Power outage return | Preset fail open or fail close operation during power loss | Chargable |
Electronic overload protection | Bidirectional electronic overload protection with output terminals | Chargable |
Brushless DC motor drive | Brushless DC motor drive with high efficiency and low heat output | Chargable |
Current position feedback | Current position transducer for valve position feedback | Chargable |
Advanced H class configuration | High temperature resistant components with enhanced environmental protection | Chargable |
