How Failsafe Valves and Failsafe Actuators Improve Process Safety

Process safety depends on what equipment does when power, control, or another essential utility is lost. If an automated valve stops in an unsafe position, the process may continue feeding hazardous media, lose cooling flow, or fail to isolate part of the system.

A failsafe actuator addresses this problem by moving the valve to a predefined safe position. The objective is to turn an abnormal event into a predictable physical response.

What Makes a Valve System “Failsafe”?

Failsafe Valve vs. Failsafe Actuator: What Is the Difference?

The valve controls the process medium. The actuator supplies the movement that opens, closes, or positions the valve. A failsafe arrangement combines both so that the valve can reach its required safety position after a defined failure.

The valve must suit the medium, pressure, temperature, shutoff duty, and torque demand. The actuator must still complete the emergency stroke under real operating conditions.

What Happens to an Automated Valve When Power or Control Is Lost?

A conventional electric actuator needs power to move. If supply power disappears during travel, the valve may stop before reaching the required endpoint unless another energy source is available.

A fail safe electric actuator is designed around a predetermined response. When its defined trigger occurs, stored energy drives the valve to the selected safety position.

Before selecting hardware, engineers should answer three questions:

1. What failure initiates the safety action?

2. Which valve position reduces process risk?

3. What emergency stroke time is acceptable?

How Failsafe Valves and Actuators Reduce Process Risk

Moving the Process to a Predictable Safe Position

Safe does not always mean closed. One process may require immediate isolation of fuel or chemicals. Another may need a valve to open so cooling water, drainage, or another protective flow can continue.

Process concern	Possible safe action	Purpose
Hazardous feed continues	Fail closed	Isolate the source
Cooling flow must continue	Fail open	Protect equipment
Tank inlet risks overflow	Fail closed	Stop inflow
Protective bypass is required	Fail open	Maintain a safe flow path

These examples illustrate the logic only. The final position should come from the plant’s process hazard analysis.

Isolating Hazardous Flow or Maintaining Critical Flow

In oil and gas or chemical service, emergency positioning may isolate a pipeline during an outage. In water treatment, it can support controlled shutdown and help reduce overflow or equipment-damage risks. AOITEC also applies failsafe technology to power and energy systems.

Application case: In oil and gas and petrochemical projects, our actuator solutions have been used on storage tanks, loading systems, and pipeline isolation valves.

Customers required remote electric control, reliable operation, and rapid shut-off or isolation under critical conditions; project results included better operational safety, automation, and response capability.

The advantage is consistency. A designed response does not depend on an operator reaching a manual valve after power has failed.

Why Controlled Emergency Valve Movement Also Matters

Fast closure can be valuable in ESD service, but maximum speed is not always the safest choice. In liquid systems, very rapid movement can contribute to pressure transients and water hammer.

Actuator emergency stroke time should therefore be treated as one part of the required shutdown response time. Valve size, differential pressure, fluid behavior, piping layout, shutdown objectives, and the response times of the sensing and logic elements should all be considered. A suitable fail-safe valve actuator must provide sufficient torque while meeting the required final-element response time.

Where Failsafe Actuation Fits into a Process Safety System

From Sensors and Shutdown Logic to the Final Valve Element

Fail-safe actuation is one part of a wider protection chain:

abnormal condition → sensor(s) / detection → logic solver or shutdown logic → final element (actuator + valve) → defined safe state

The actuator converts a shutdown or control command into valve movement. It does not replace sensors, alarms, logic solvers, relief devices, or other safeguards. A fail-safe actuator feature by itself does not establish the SIL capability of the complete safety instrumented function; functional safety must be assessed at the SIF level.

Designing for Power Failure, Signal Failure, and Utility Loss

Engineers should distinguish between loss of mains power, loss of a control signal, an ESD command, and loss of another utility. The system should define both the trigger and the target position before commissioning.

A practical design sequence is:

1. Identify the credible failure.

2. Define fail open or fail closed.

3. Confirm worst-case valve torque.

4. Define acceptable emergency stroke time.

5. Verify the available emergency-energy method.

This prevents a vague “failsafe” requirement from producing an unclear field response.

Position Feedback, Testing, and Readiness for the Next Emergency

A safety action should be verifiable. Actuator position feedback can confirm that the actuator output has reached the intended endpoint, but it does not necessarily prove that the valve has achieved the required process isolation or flow condition. Where this distinction is important, the feedback and proof-test strategy should verify the actual safety function. Functional testing can reveal changes in torque, wiring, mechanics, or stored-energy performance.

AOITEC applies multi-stage inspection and functional testing in actuator production, with quality control aligned with ISO 9001. Our actuator designs also include IP68 protection for harsh environments.

How to Select a Fail Safe Valve Actuator for Process Safety

Define Fail Open, Fail Closed, and the Required Emergency Response Time

Selection should begin with the hazard. Determine the required safe position, then define how quickly the valve should get there and whether rapid or controlled movement is appropriate.

For ball and butterfly valves, size the actuator based on the valve’s maximum required operating torque under the specified worst-case conditions, rather than on actuator no-load torque or nominal running torque alone. Consider breakaway, running, and seating or unseating torque as applicable, together with differential pressure, seat friction, temperature, contamination, and valve condition.

Check Valve Torque, Valve Type, Environment, and Control Requirements

Key selection factors include:

· valve type, size, and mounting interface

· worst-case torque

· required safe position

· emergency travel time

· supply voltage

· on-off or modulating control

· feedback and system integration

· ambient and enclosure requirements

· hazardous-area requirements, where applicable

AOITEC develops actuator solutions for quarter-turn valves and supports standard on-off and modulating applications, as well as high-speed, BLDC, explosion-proof, and failsafe duties. This lets the actuator concept match the process requirement instead of treating every valve application the same way.

When a Supercapacitor Failsafe Actuator Makes Sense

A supercapacitor failsafe actuator is useful when the valve must complete an emergency movement after normal power is lost without depending on an external backup source. The built-in supercapacitor stores energy for the safety stroke.

AOITEC’s supercapacitor failsafe actuator automatically positions the valve during power loss. Compared with traditional battery-based backup, the supercapacitor approach provides faster charging, longer service life, and reduced maintenance requirements. It is intended for ESD, oil and gas, chemical processing, water treatment, and power and energy applications.

Consider a process line where site power loss requires flow isolation. During normal operation, the actuator operates the quarter-turn valve. When power disappears, stored energy drives it to the predetermined safe position. The emergency positioning capability is therefore built into the actuator-and-valve package, reducing reliance on manual intervention after loss of normal power.

For us at AOITEC, that is the practical value of failsafe automation: helping the final valve element perform a defined safety action when normal operation is no longer available.

FAQ

Q: What is a fail safe valve actuator and how does it work?

A: A fail safe valve actuator moves a valve to a predetermined safe position when a defined failure occurs. Depending on the process, that position may be fully open or fully closed.

Q: How does a fail safe electric actuator improve process safety during a power failure?

A: It provides a planned valve response after normal power is lost. Stored energy allows the actuator to complete the required safety stroke rather than leaving valve position to chance.

Q: Should a failsafe actuator be fail open or fail closed?

A: It depends on the hazard. Fail closed can isolate hazardous flow, while fail open may maintain cooling, drainage, or another protective flow path.

Q: What is the difference between a supercapacitor failsafe actuator and a spring return actuator?

A: Both can provide emergency positioning, but they store energy differently. A supercapacitor stores electrical energy for a motor-driven stroke, while a spring-return actuator stores mechanical energy in a spring.

Q: How do I choose the correct fail safe actuator for a ball valve or butterfly valve?

A: Start with safe position and worst-case torque, then evaluate stroke time, supply voltage, control mode, feedback, installation conditions, and any hazardous-area requirements.
